| Product Name: | High Frequency Welded Tube Mill Equipment Precise For Pipe Thickness 6mm-12mm | Control System: | PLC |
|---|---|---|---|
| Material: | Carbon Steel, Alloy Steel, Stainless Steel | Forming Method: | Roll Forming |
| Forming Speed: | 0-20m/min | Voltage: | 380V/50Hz/3Phase |
| Pipe Thickness: | 6mm-12mm | Keywords: | Welded Tube Mill Equipment |
| Highlight: | Precise tube mill equipment,high frequency welded tube mill equipment,pipe thickness 6mm welded tube mill |
||
t Description:Welded Pipe Mill is a state-of-the-art product designed for efficient and precise fabrication of welded pipes. It combines advanced technology and innovative design to provide a seamless and effective solution for the manufacturing of high-quality welded pipes.
The Welded Pipe Mill utilizes the Roll Forming method, which involves shaping a continuous metal strip into a circular cross-section by passing it through a series of rollers. This method ensures consistent and precise shaping of the pipes, resulting in a smooth, uniform surface finish.
The Welded Pipe Mill uses the High Frequency Induction Welding method, which involves heating the edges of the metal strip with high frequency electrical currents and then applying pressure to join them together. This method ensures a strong and durable weld, with minimal distortion and no need for additional filler material.
The Welded Pipe Mill is equipped with a highly efficient Water Cooling System, which helps to maintain the temperature of the pipes during the welding process. This system ensures that the pipes are cooled at a controlled rate, preventing any deformation or damage to the welded area.
The Welded Pipe Mill is capable of producing pipes with a length range of 6m-12m. This flexibility allows for the production of pipes in various lengths, catering to the specific requirements of different industries and applications.
The Welded Pipe Mill is powered by a High Frequency Induction Welding power source, with a range of 100KW-1000KW. This high power ensures efficient and precise welding of the pipes, resulting in strong and durable joints.
In conclusion, the Welded Pipe Mill is a highly advanced and efficient product that offers a seamless solution for the fabrication of welded pipes. With its Roll Forming method, High Frequency Induction Welding, Water Cooling System, and versatile pipe length and power options, it is the ideal choice for any pipe manufacturing needs.
| Product Name | Welded Pipe Mill |
|---|---|
| Pipe Thickness | 6mm-12mm |
| Material | Carbon Steel, Alloy Steel, Stainless Steel |
| Pipe Diameter | 300-508mm |
| Forming Method | Roll Forming |
| Forming Speed | 0-20m/min |
| High Frequency Power | 100KW-1000KW |
| Pipe Length | 6m-12m |
| Cooling System | Water Cooling |
| Control System | PLC |
The Welded Pipe Mill produced by Hebeitengtian is a highly efficient and advanced machine used for the fabrication and production of welded pipes. It is designed to meet the growing demand for high-quality welded pipes in various industries such as oil and gas, construction, and manufacturing.
The Welded Pipe Mill is suitable for a wide range of applications, including:
The Welded Pipe Mill from Hebeitengtian has the following features:
The Welded Pipe Mill can be used in various scenes and scenarios, such as:
The Welded Pipe Mill is also ideal for scenarios where a large quantity of pipes is needed within a short period, as it has a high production capacity and efficient operation.
With its advanced technology and reliable performance, the Welded Pipe Mill from Hebeitengtian is a top choice for businesses looking to increase their production of high-quality welded pipes.
Brand Name: Hebeitengtian
Model Number: 508
Place of Origin: SHIJIAZHUANG, HEBEI, CHINA
Certification: CE, ISO9000, BV
Minimum Order Quantity: 1
Price: USD 25000000.0
Packaging Details: Packaging Details
Delivery Time: 12 months
Payment Terms: Payment Terms
Supply Ability: 5 sets per year
Voltage: 380V/50Hz/3Phase
Pipe Diameter: 300-508mm
Welding Speed: 0-25m/min
High Frequency Power: 100KW-1000KW
Pipe Thickness: 6mm-12mm
Key Words: Welded_Pipe_Production_Line, Welded_Pipe_Making_Machine, Welded_Pipe_Manufacturing_System
The Welded Pipe Mill is carefully packaged and shipped to ensure safe delivery to our customers.
Each component of the Welded Pipe Mill is individually wrapped and secured to prevent any damage during transportation.
The main body of the machine is covered with a protective layer to prevent scratches and other surface damage.
All accessories and spare parts are placed in separate boxes and labeled for easy identification.
We offer both sea and air shipping options for our customers.
For sea shipping, the Welded Pipe Mill is loaded onto a sturdy wooden pallet and securely fastened with straps to prevent movement during transit.
For air shipping, the machine is packaged in a durable, lightweight material to reduce weight and ensure efficient transportation.
We work with reliable shipping companies to ensure timely and safe delivery of our products to customers around the world.
Upon shipment, customers will receive a tracking number to monitor the status of their order.
For any special shipping requests, please contact our customer service team for assistance.
