HG508 MS Steel Tube Making Machine For Round Pipe And Square Tube

Large Image : HG508 MS Steel Tube Making Machine For Round Pipe And Square Tube

Product Details:

Place of Origin:	China
Brand Name:	TENGTIAN
Certification:	CE, ISO9001
Model Number:	HG508

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	300days
Payment Terms:	CIF
Supply Ability:	30 SETS PER YEAR

Contact Now

Detailed Product Description

Material Width:	100-300mm	Cutting Length:	Any Length
Control System:	PLC	Roller Stations:	18-20 Stations
Cutting System:	Hydraulic Cutting	Cutting Tolerance:	±2mm
Highlight:	MS steel tube making machine , Round steel tube making machine , Square steel pipe making machine

Product Description:

HG508x16 High frequency welded pipe production line is used to manufacture welded steel pipe of Φ219mm-Φ508mm,thickness 4.0-16.0mm, square pipe 170x170-400x400mm, thickness 4.0-16mm . After we absorbed advanced pipe making technology from all over world, our innovative designed production line and each single unit of the production line is not only economical but also practical.

Machine Details:

(1)Raw material:
Material Quality	Q195,Q235B,Q355B,Galvanized Steel,MS,CR,HR
Mechanical properties	σb≤500Mpa,σs≤325MPa
Strip Width	680-1600mm
Strip Thickness	4.0-16mm
Coil ID	Φ508-610mm
Coil OD	Φ1200mm-2100mm
Coil Weight	20.0T
Finished Product Size and purpose
Pipe Size	Round Pipe: φ219-φ508 mm T:4.0-16mm Square Pipe:¨ 170x170-400x400mm T:4.0-15mm
Length	4-6m
Application	Structure

HG508 MS Steel Tube Making Machine For Round Pipe And Square Tube 0
