| Product Name: | Automatic Pipe Paking Machine Steel Tube Making Machine 200KW Roll Forming Tube Mill | Applicable Materials: | HG60 |
|---|---|---|---|
| Equipment Specification: | Customer Specified | Product Speed: | Max 100m / Min |
| Cut Off Error: | ± 2mm | Floor Area: | 60x12 M |
| Power: | 200KW | Shape: | Round Square Rec. |
| Highlight: | automatic steel tube making machine,Roll Forming steel tube making machine,Roll Forming steel pipe making machine |
||
automatic pipe paking machine Steel Tube Making Machine 200KW Roll Forming Tube Mill
| 1 | uncoiler |
| 2 | straight head |
| 3 | pinch leveling machine |
| 4 | shear welder |
| 5 | horizontal accumulator |
| 6 | 7 Sets Roll Forming Sets |
| 7 |
cutter saw |
| 8 | Roller conveyer finished product |
| 9 |
auto stacking machine |
| 10 |
Electric control cabinet |
| Product overview |
Feeding device |
| The automatic pipe paking machine Steel Tube Making Machine 200KW Roll Forming Tube Mill unit has a reasonable design structure, touch screen man-machine interface, PLC digital program control, coding and fixed length, high degree of automation, smooth process, good product quality, stable mechanical performance, high yield, saving labor and time, and the overall linkage is fixed. High precision | It is main include frame, electric motor, brake unit, circling direction transfer power axle of the reduce velocity, press & carry roll, pressure air system of guide roll, inspected velocity unit; it can supply the strip steel to accumulator and the mean times it will transfer the carry velocity information to electric control system, when we demand stop carry the material to this unit, it will stop roll to the electric motor and press& carry material roll by the break, and also could adjust the velocity to carry electric motor and the unit carry material velocity. |
|
Tube thickness |
0.9-3.0mm |
|
Tube Length |
8-12 M |
|
Speed |
80 m/min |
|
Cut length |
3m |
|
Cut off error |
±0.5mm |
|
Hydraulic station |
AC11KW |
|
Raw Material Conditions |
Hot rolled or cold rolled steel strip (meet JT/T457-2007,GB345B) |
| single cone uncoiler | Hydraulic pressure increases and single cone |
|
Thickness of strip |
2.0 - 6.0mm |
|
Strip Width |
50 - 130mm |
|
Max Coil Weight |
3000Kg |
|
working speed |
0-40m / min |
|
Main motor |
32kw 1 sets Siemens |
P.S.
we can design the automatic pipe paking machine Steel Tube Making Machine 200KW Roll Forming Tube Mill according to the customer detail require.
It is our honor to answer all your questions, welcome to consult
single cone uncoiler
Shear and welder
horizontal spiral accumulator
